Ultra SVQ07 Diverter Cartridge for A3023 Triple Shower Mixer Valves

Technical Information
Total Length: 100mm (10cm)
Diameter of Main Barrel: 40mm (4cm)
Distance Between Locating Pins (centre to centre): 22mm (2.2cm)
Length of Barrel Body (Including Locating Pins): 50mm
Spindle Length: 60mm (6cm)

Used in:

- Hudson Reed TSVT004 Twin Concealed Shower Valve with Diverter
- Hudson Reed BTSVT005 Triple Concealed Shower Valve With Diverter
- Premier QUEV52 Twin Thermostatic Diverter Shower Valve
- Hudson Reed REI3407 Twin Valve With Diverter
- Hudson Reed SQR3207 Twin Thermostatic Diverter Shower Valve
- Hudson Reed TSVT005 Triple Concealed Shower Valve with Diverter
- Hudson Reed A3007 Twin Thermostatic Diverter Shower Valve
- Hudson Reed ART3207 Twin Thermostatic Diverter Shower Valve
- Hudson Reed BTSVT004 Twin Concealed Shower Valve With Diverter
- Hudson Reed A3023 Triple Thermostatic Diverter Shower Valve

Important - The new replacement for this cartridge is cream in colour and has what appears to be 4 outlets at the bottom, with 2 blocked off. This is correct and is the cartridge that you need.

Frequently Asked Questions: Ultra SVQ07 Diverter Cartridge

Question: How do I install this spare part in the shower valve?
Answer: The Ultra SVQ07 can be fitted in the Hudson Reed A3023 valve by:
1. Remove the screw caps. Use a 2.5mm Allen key to loosen the grub screw and remove the handles.
2. Remove the sleeves and slide out the concealing plate.
3. Remove the retaining nut by turning it anti-clockwise.
4. Use a box spanner to remove the faulty diverter.

5. Apply a small amount of silicon grease on all the O-rings of the new Ultra SVQ07 diverter cartridge.
6. Insert it in the valve and reassemble.

Question: Do I have to use silicone grease on the cartridge?
Answer: Yes, you have to. Silicone grease made for plumbing must be applied to the O-rings of the new Ultra SVQ07. This is to make sure the diverter cartridge will sit properly in the valve and the grease will protect the rings from friction and abrasion.

Question: What are the indicators the diverter cartridge needs to be replaced?
Answer:
1. Water is not redirecting from tap to shower head.
2. Water is leaking from the tap while the shower is in use.
3. Low water flow when using the shower.

Fixing the Ultra/Hudson Reed A3023 with the SVQ07 can address such issues.
