Vado ST-212K-CAR 45mm Hydroflow Single Lever Ceramic Disc Diverter Cartridge | Low Pressure | Zoo | Chelsea | Evolve | Magma

SUMMARY

Vado ST-212K-CAR Hydroflow low pressure single lever ceramic disc diverter cartridge.

This Vado cartridge is used on the following single lever valves:
- Chelsea CHE-130/SL 2 hole bath shower mixer single lever wall mounted without shower kit
- Chelsea CHE-130M
- Chelsea CHE-137/SL
- Chelsea CHE-137/M
- Evolve EVO-130/SL
- Evolve EVO-130M
- Evolve EVO-137/SL
- Evolve EVO-137/M
- Magma MAG-130/SL
- Magma MAG-130M
- Magma MAG-137/SL
- Magma MAG-137/M
- SEN-130M
- SEN-137M
- ZOO-130/SL
- ZOO-130M
- ZOO-137/SL
- ZOO-137M
- Fits Marflow Antro 365 (large) bath mixer tap

Cartridge Length (from top of metal handle to bottom of cartridge (not including the two positioning pins)): 81mm
Width of diverter barrel body: 45.2mm (at the widest point)
Diameter at top whote plastic spline: 32.3mm (at the widest point, as this part tiers down to 28.5mm and 23mm respectively)
Diameter of top Square Metal Handle Spindle: 10.4mm (from flat side to flat side, not corner to corner)
Diameter of top Squares Spindle including the semi circle on both sides: 14mm
Cartridge Colour: White, beige / cream, silver and red.
Type: Push fit
Cartridge Material: Plastic cartridge body with ceramic discs inside with metal handle connector.
Number of Water Inlets: 2

Frequently Asked Questions: Vado Hydroflow Single Lever Cartridge (ST-212K-CAR)
Question: Tap started to leak. Do I need to replace the cartridge?
Answer: There are a number of causes that lead to a leaking tap. It can be the water pressure, the O-rings or the cartridge itself.

Question: The handle is stiff when I open and close the tap. Is it a cartridge problem?
Answer: If you have just replaced the cartridge, the collar or the handle might be screwed too tight. If you have not recently replaced the cartridge, soap scum or hard water minerals might have hardened. You can clean the soap scum and apply plumbing grease on the cover, spindle and O-ring.

Question: How do I replace the cartridge?
Answer: The Vado ST-212K-CAR is the replacement cartridge for Vado monobloc lever taps. Search for the grub screw. This is usually found at the back of the handle or under the red/blue indicator button. Once the grub screw is out, lift the handle to remove. Remove the shroud and the retaining collar. Then pull the single lever cartridge out.

Question: Water is leaking from under the tap handle.
Answer: Leaks are among the common tap problems. This might be due to a failed lever cartridge which needs to be replaced from time to time. The Vado Hydroflow Single Lever Cartridge is the spare part for the tap models stated above. Replacing the cartridge can be a long-term solution.

Question: Is this suitable for high pressure?
Answer: ST-212K-CAR is for Vado tap models Chelsea, Evolve, Sense and Zoo which are low pressure taps. Please feel free to contact us with a photo of the old cartridge. We will assist you in finding the correct spare part.

Spare Part: Vado Hydroflow Single Lever Cartridge (ST-212K-CAR)
Installation: Push-Fit
Number of O-Ring: 1
