Thermostatic Shower Milan Modern Cartridge (Victorian Plumbing) - 294HD6V

SUMMARY

Thermostatic Shower Milan Modern Cartridge (Victorian Plumbing) - 294HD6V. There are two versions of the Milan shower bar which use two different cartridges. Please remove the cartridge from the valve before purchasing to ensure this is the correct version you require.

Cartridge Measurements:
Total Length: 87mm (including wax thermostat at bottom)
Total Length: 84mm (excludin gwax thermostat at bottom)
Diameter at Widest Point: 28mm
Diameter at Stop Ring Splines (tooth to tooth): 22.5mm
Top Spline Diameter: 7.6mm
Top Spline Teeth / Notches: 20
Diameter at Top O'ring: 27mm
Diameter at Middle O'ring: 24.5mm
Diameter at Bottom O'ring: 16.8mm
Fitting Type: Screw Fit. Diameter of thread is 25.8mm
Colour: Brass
