VOLA VR3277K Thermostatic Cartridge (Hastings) - Compatible Spare. The VR3277K cartridge controls water flow and water temperature in the shower valve, therefore if your shower is experiencing poor performance in water mixing or if it is dripping, this cartridge is likely to fix the problem.

Only the cartridge is included. The removal tool is not included.

Vola VR3277K Dimensions

Dimensions
Total Length: 102.2mm (excluding locating pins)
Diameter at Widest Point: 40mm
Top Spline Diameter: 7.6mm
Top Spline Teeth / Notches: 20
Middle Spline Diameter (brass): 18.9mm
Bottom Spline Diameter (plastic): 29.8mm
Barrel Diameter: 40mm
Distance Between Locating Pins (centre to centre): 24.5mm

Frequently Asked Questions: Vola / Hastings Thermostatic Cartridge VR3277K

Question: How do I know if I should change the cartridge in my shower?
Answer: There are three main indications that the thermostatic cartridge needs replacement:
1. Unstable water temperature when showering.
2. Water flow slows down to a trickle.
3. Stiff thermostat control handle.

If you are experiencing one or all of the issues above, getting a new Vola VR3277K
shower cartridge can potentially make your shower run as good as new.

Question: Should I use silicone grease when installing the Vola thermostatic cartridge?
Answer: Yes, you must apply a thin coating of plumber’s silicone grease on the O-ring of the new Vola VR3277K. Doing this will protect the O-ring from premature wear and tear.

Question: I turn the handle but the temperature is always hot.
Answer: If your cold water supply is not clogged, this can be caused by a Vola thermostatic cartridge gone defective.

Question: My shower is leaking from the handle. What should I do?
Answer: Given that your shower’s valve seat has no problem, you can try replacing the Vola shower cartridge VR3277K. Most of the time, this will solve the problem.

Question: I need this shower cartridge spare part fast!
Answer: This VR3277K Vola thermostatic shower cartridge can be dispatched on the same day as you ordered provided it is before 3:00 in the afternoon on a weekday. We have a next day delivery option available at checkout.

Question: I’m not sure that this is the right part for my shower.
Answer: You can have a look at other Vola / Hastings spare parts we offer. You can also use our Find a Part page so that you can be 100% sure you are purchasing the correct spare part. We will do everything that is possible to reply to your query within one working hour.
