Bristan DIV 00141592 Diverter Cartridge Assembly for PM TSHCDIV C DIV Artisan, Prism and Quadrant Shower Valves

SUMMARY

Bristan DIV 00141592 2-Way Diverter Assembly for PM TSHCDIV C DIV Artisan, Prism and Quadrant Shower Valves

Manufacturer: Bristan
Spare Part: Diverter Assembly (Bristan 00141592)

The Bristan Diverter Assembly 00141592 with housing can be dispatched on the next working day when purchased before 3:00 PM, Monday to Friday.

Diverter mechanisms redirect water flow from a bathtub tap to a shower head outlet and vice versa. This mechanism sits on a two-way shower valve where water can be directed to a tap spout or a shower with a turn of a switch. This valve type is more resistant to mineral debris and rust buildup. Or it can be found on the tap itself in the form of a plunger which is common on single-handle taps.

Bristan 00141592 diverter spare part is suitable for two-way shower valves such as the Artisan, Prism, and Quadrant; produced by the company.

Water flow should not spill from the tap when diverting flow to a showerhead. Should it drip out of the tap when the shower head is in use, the diverter likely needs to be replaced. Two more clues a diverter assembly (or its cartridge) requires to be changed is if water flow is not able to switch back and forth from the tap to the shower; and a leak from its spindle. Diverter valves can cease to work properly due to inevitable damage caused by wear and tear prolonged use.

Aside from the Bristan 00141592, we supply a wide range of shower diverter spare parts.

Having trouble identifying the right shower spare part?
- Please leave us a message or call us. We will surely help you in determining the shower spare part you need.

How to: Replacing a Diverter Assembly in a Bath Tap
Shower valves can come with one to three knobs that control various functionalities: switching the water flow on or off, administering the preferred temperature, and directing water flow to the desired water outlet (shower or tap). Since shower valve models differ, methods for replacing a diverter are not the same. Below are some general instructions on how to replace a diverter assembly, particularly the 00141592 Bristan diverter cartridge.

Before beginning the replacement, please ensure hot and cold water supply pipes are isolated.

Two-Way Shower Valve with the Bristan 00141592
1: Use an unsharpened tool to remove the indicator on the water flow diverter control handle.
2: With a Phillips screwdriver, unscrew the handle.
3: Separate the diverter sleeve. Then use a socket wrench to pull the diverter out together with its nylon washer.
4: Use a brush to clean the diverter valve.
5: Apply heat-proof grease on the new Bristan 00141592 diverter cartridge.
6: Fit in the new diverter and restore the handle and indicator.
7: Test to see if the replacement attempt is successful.

Diverter Located on the Bath Tap
1: Remove the tap. There should be a screw near the base of the tap.

If no screw is found, the tap must have threads to adjoin it to the wall. In this case, unscrew the whole tap using a wrench. Stop the attempt if you find resistance while loosening the tap. It might be better to call a professional plumber.
2: With the tap removed, the supply pipe can now be seen. Clean by removing dirt from the pipe and stick a thread seal tape on the pipe’s end if it has threads.
3: Install the new diverter spout.
4: Test to see if the replacement attempt is successful.
